VL-VPR-108 Over/Under-Voltage Protector, 100A
The over/under-voltage protector continuously monitors the supply and disconnects the load when the voltage moves outside the safe range, reconnecting once power returns to normal — protecting equipment on unstable grids.
| Parameter | Specification |
|---|---|
| Voltage Calibration | Voltage +-10% adjustable. A13 |
| Model | TOVPD1-60-EC |
| Power Supply | 230VAC 50/ |
| Frequency | 60 Hz |
| Max. load power | 1~40A Adjustable(default:40A) |
| Over-Voltage Protection Value Range | 230V~300~OFF(default:270V) |
| Over-Voltage Recovery Voltage Range | 225V–295V(default:250V) |
| Over-Voltage Protection Action Time | 0.1s~30s(default value:0.5s) |
| Over-Voltage Recovery Delay Time | 1s~500s(default:30s) |
| Mounting | 35 mm DIN rail |
| Standard | IEC (compatible) |
Protects household appliances, HVAC, motors, pumps and sensitive electronics on unstable or generator-backed grids.
Datasheet, type-test report and CAD drawing are being finalized and will be published here shortly. Need them sooner? Request them via the quote form and our team will send them directly.
Packaging, MOQ, lead time and HS code are being finalized. Need this sooner? Contact us via the Request a Quote form.
Send us your circuit requirements or a competitor part number — our engineers will match the exact model and quote within 24 hours.
