VOLTALUME VL-MCCB-02 Series Molded Case Circuit Breaker — Advanced-technology protection scaling from 6A to 1250A.
The VOLTALUME VL-MCCB-02 is a newly developed molded case circuit breaker using advanced technology, with rated insulation voltage up to 800V, suitable for AC 50/60Hz systems, rated operating voltage up to 690V, and rated current from 6A to 1250A. It distributes electrical energy and protects lines and power equipment from overloads, short circuits, undervoltage, and other faults, and provides motor protection during infrequent starts. Compact, with high breaking capacity and short (or no) arcing, it installs vertically or horizontally — an ideal solution for industrial applications.
| Model | Frame current | Rated current range | Icu 400V (kA) | Ics 400V (kA) | Poles |
|---|---|---|---|---|---|
| VL-MCCB-02-63L/M | 63A | 6–63A | 25–50 | 18–25 | 3/4 |
| VL-MCCB-02-125L/M/H | 125A | 10–125A | 35–85 | 26–42.5 | 2,3,4 |
| VL-MCCB-02-250L/M/H | 250A | 125–250A | 35–100 | 26–50 | 2,3,4 |
| VL-MCCB-02-400L/M/H | 400A | 225–400A | 50–100 | 35–70 | 3,4 |
| VL-MCCB-02-630L/M/H | 630A | 400–630A | 50–100 | 35–70 | 3,4 |
| VL-MCCB-02-800M/H | 800A | 630–800A | 75–100 | 50–75 | 3,4 |
| VL-MCCB-02-1250 | 1250A | 800–1250A | 85 | 42.5 | 3,4 |
Industrial power distribution, motor protection circuits, applications requiring vertical or horizontal mounting flexibility and tiered breaking-capacity selection.
Technical documentation for this product (datasheet, type-test report, CAD drawing) is being finalized and will be published here shortly. Need it sooner? Contact us via the Request a Quote form and our team will send it directly.
Packaging details, minimum order quantity, lead time and HS code for this product are being finalized and will be published here shortly. Need this information sooner? Contact us via the Request a Quote form.
Send us your circuit requirements or a competitor part number — our engineers will match the exact model and quote within 24 hours.
